MediaTek Genio for industrial automation

Genio’s industrial capabilities go beyond edge AI inference. The SoC integrates TSN-capable Gigabit Ethernet, and the RITY BSP includes the full industrial software stack: linuxptp for IEEE 1588 time synchronization, OPC-UA via libopen62541, PREEMPT_RT for soft real-time, and Jailhouse for hard real-time partitioning. This makes Genio viable as an industrial edge computer that combines sensor fusion, AI inference, and deterministic industrial protocol handling on a single board.

Key Insights

• TSN is native in silicon — Genio 510/520/700/720/1200 all include a TSN-capable GbE MAC; no external TSN switch required for single-hop setups
• meta-mediatek-tsn Yocto layer provides the full TSN software stack — linuxptp, tc with taprio/CBS, and OPC-UA
• PREEMPT_RT is included in the RITY BSP — enables soft real-time Linux for control loops that need deterministic response in the 50–500µs range
• Jailhouse hypervisor partitions CPU cores between Linux and a bare-metal RTOS — use it when you need hard real-time guarantees alongside Linux
• OPC-UA (libopen62541) ships in the rity-tsn packagegroup — server and client modes supported out of the box

TSN (Time-Sensitive Networking) on Genio

TSN adds deterministic delivery and time synchronization to standard Gigabit Ethernet. The key standards relevant for industrial automation:

Standard	What it provides	Genio support
IEEE 802.1AS	Time synchronization (gPTP)	✅ via linuxptp
IEEE 802.1Qbv	Time-Aware Shaper (TAS/taprio)	✅ via tc taprio
IEEE 802.1Qav	Credit-Based Shaper (CBS)	✅ via tc CBS
IEEE 802.1Qcc	Stream reservation	✅ via SR classes

Setting up gPTP time synchronization

# Install linuxptp (from meta-mediatek-tsn)
# On target:

# Check that PTP hardware clock is available
ls /dev/ptp*
# /dev/ptp0

# Query PTP clock capabilities
ethtool -T eth0 | grep -E "SOF_TIMESTAMPING|PTP"

# Start gPTP daemon as grandmaster (time source)
ptp4l -i eth0 -f /etc/linuxptp/gPTP.cfg --masterOnly 1 &
phc2sys -a -rr &

# Or as slave (sync to network time)
ptp4l -i eth0 -f /etc/linuxptp/gPTP.cfg -s &
phc2sys -a -rr &

Verify synchronization:

pmc -u -b 0 'GET CURRENT_DATA_SET'
# Should show offset close to 0 ns when synced

Configuring Time-Aware Shaper (taprio)

taprio schedules transmission windows for different traffic classes, ensuring control traffic is transmitted in guaranteed time slots:

# Configure taprio schedule
# 8 queues, 1ms cycle: 200µs for control (queue 0), 800µs for best-effort
tc qdisc replace dev eth0 parent root handle 100 taprio \
  num_tc 2 \
  map 1 1 1 1 1 1 1 1 \
  queues 1@0 1@1 \
  base-time $(date +%s%N)000 \
  sched-entry S 01 200000 \
  sched-entry S 02 800000 \
  flags 0x2

Credit-Based Shaper (CBS) for audio/video streams

tc qdisc replace dev eth0 parent root mqprio \
  num_tc 3 map 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 queues 1@0 1@1 2@2 \
  hw 0

tc qdisc replace dev eth0 parent 100:1 cbs \
  idleslope 10000 sendslope -990000 \
  hicredit 153 locredit -1389 offload 1

OPC-UA with libopen62541

libopen62541 is the open-source OPC-UA implementation included in the RITY rity-tsn packagegroup.

Simple OPC-UA server on Genio

#include <open62541/server.h>
#include <open62541/server_config_default.h>

int main(void) {
    UA_Server *server = UA_Server_new();
    UA_ServerConfig_setDefault(UA_Server_getConfig(server));

    // Add a variable node: temperature sensor reading
    UA_VariableAttributes attr = UA_VariableAttributes_default;
    UA_Float temperature = 23.5f;
    UA_Variant_setScalar(&attr.value, &temperature, &UA_TYPES[UA_TYPES_FLOAT]);
    attr.displayName = UA_LOCALIZEDTEXT("en-US", "Temperature");
    attr.accessLevel = UA_ACCESSLEVELMASK_READ | UA_ACCESSLEVELMASK_WRITE;

    UA_NodeId nodeId = UA_NODEID_STRING(1, "temperature");
    UA_NodeId parentNodeId = UA_NODEID_NUMERIC(0, UA_NS0ID_OBJECTSFOLDER);
    UA_NodeId parentReferenceNodeId = UA_NODEID_NUMERIC(0, UA_NS0ID_ORGANIZES);
    UA_QualifiedName browseName = UA_QUALIFIEDNAME(1, "Temperature");

    UA_Server_addVariableNode(server, nodeId, parentNodeId,
        parentReferenceNodeId, browseName,
        UA_NODEID_NUMERIC(0, UA_NS0ID_BASEDATAVARIABLETYPE),
        attr, NULL, NULL);

    // Run server on port 4840
    UA_StatusCode retval = UA_Server_runUntilInterrupt(server);
    UA_Server_delete(server);
    return retval == UA_STATUSCODE_GOOD ? 0 : 1;
}

Build with:

gcc -o opc_server opc_server.c \
  $(pkg-config --cflags --libs open62541)

Clients connect to opc.tcp://<genio-ip>:4840.

Real-time Linux (PREEMPT_RT)

The RITY BSP includes PREEMPT_RT kernel patches. With PREEMPT_RT, most kernel code paths become preemptible, reducing worst-case interrupt latency from milliseconds to the 50–500µs range.

Enable PREEMPT_RT in Yocto

# conf/local.conf
KERNEL_FEATURES:append = " features/preempt-rt/preempt-rt.scc"

Or in your kernel bbappend:

LINUX_KERNEL_TYPE = "preempt-rt"

Verify RT kernel is running

uname -r
# Should include "rt" in the version string
# e.g., 6.1.57-rt16-v8+

# Check preemption model
grep CONFIG_PREEMPT /boot/config-$(uname -r)
# CONFIG_PREEMPT_RT=y

Configuring a real-time control thread

#include <pthread.h>
#include <sched.h>

void* control_loop(void* arg) {
    // Set real-time priority
    struct sched_param param = { .sched_priority = 80 };
    pthread_setschedparam(pthread_self(), SCHED_FIFO, &param);

    // Lock memory to prevent page faults
    mlockall(MCL_CURRENT | MCL_FUTURE);

    struct timespec next;
    clock_gettime(CLOCK_MONOTONIC, &next);

    while (1) {
        // 1ms control loop
        next.tv_nsec += 1000000;
        if (next.tv_nsec >= 1000000000) {
            next.tv_nsec -= 1000000000;
            next.tv_sec++;
        }

        // --- Do control work here ---
        read_sensors();
        compute_control_output();
        write_actuators();
        // ---

        clock_nanosleep(CLOCK_MONOTONIC, TIMER_ABSTIME, &next, NULL);
    }
    return NULL;
}

Isolate a CPU core for the RT thread:

# Kernel command line: isolate core 3 from the OS scheduler
isolcpus=3 irqaffinity=0-2

# Pin RT thread to isolated core
taskset -c 3 ./control_app

Jailhouse hypervisor for hard real-time

When PREEMPT_RT soft real-time isn’t sufficient — for example, motion control requiring sub-100µs determinism — Jailhouse partitions the Genio CPU cores:

Partition	Cores	Runs	Latency
Root cell	Core 0–2	Linux + full BSP + applications	OS-level (1–10ms)
Inmate cell	Core 3	Bare-metal RTOS or custom firmware	Hardware-level (<50µs)

The inmate cell has exclusive access to its CPU core and assigned memory — Linux cannot interrupt it.

# Load Jailhouse kernel module
modprobe jailhouse

# Enable Jailhouse with the board cell config
jailhouse enable /lib/firmware/jailhouse/genio720-evk.cell

# Load and start an inmate (bare-metal demo)
jailhouse cell create /lib/firmware/jailhouse/genio720-inmate.cell
jailhouse cell load my-inmate /path/to/inmate.bin
jailhouse cell start my-inmate

# Check status
jailhouse cell list

Jailhouse configurations for Genio EVKs are included in the RITY BSP. Custom carrier boards need their own cell configuration describing memory layout and peripheral assignment.

Industrial use case examples

Application	Key Genio features used
Smart gateway (IIoT edge)	TSN GbE, OPC-UA server, NPU for anomaly detection
Machine vision + PLC integration	MIPI CSI camera, TFLite NPU inference, OPC-UA client
Motor drive coordination	PREEMPT_RT, TSN taprio for deterministic EtherCAT-like control
Predictive maintenance	Multiple I2C/SPI vibration sensors, NPU time-series inference
Vision-guided robot	Multi-camera (MIPI CSI), NPU object detection, UART/SPI to servo controller
Industrial HMI	HDMI/DSI display, Weston Wayland, OPC-UA data visualization

For the RITY Yocto layer that includes the TSN and OPC-UA packages, see What is RITY? MediaTek’s Genio reference distribution explained. For AI inference on the Genio NPU that powers the machine vision component, see on-device AI without the cloud on Genio.

FAQ

Does MediaTek Genio support real-time Linux for industrial control?

Yes. The RITY Yocto BSP includes PREEMPT_RT patches for the Genio kernel. This reduces worst-case latency to the 50–500µs range for soft real-time control. For hard real-time, Jailhouse partitions a CPU core for a dedicated RTOS.

What is TSN and does Genio support it?

TSN (Time-Sensitive Networking) adds deterministic, time-synchronized packet delivery to standard Ethernet. Genio 510, 520, 700, 720, and 1200 include a TSN-capable GbE MAC. The RITY BSP includes linuxptp, taprio, and CBS in the meta-mediatek-tsn layer.

Can Genio run OPC-UA for industrial protocol integration?

Yes. libopen62541 (open-source OPC-UA stack) is included in the rity-tsn packagegroup. It supports both OPC-UA server and client modes on Genio.

What is the Jailhouse hypervisor on Genio and when should I use it?

Jailhouse is a static partitioning hypervisor that dedicates CPU cores to isolated partitions. Use it when you need hard real-time control (sub-millisecond determinism) alongside Linux-based applications on the same SoC.

---
