Building a custom Yocto meta layer for MediaTek Genio

Q: What is the minimum required file for a Yocto meta layer?

A Yocto meta layer requires only conf/layer.conf. Without it, BitBake does not recognize the directory as a layer. The layer.conf must set BBPATH, BBFILES, BBFILE_COLLECTIONS, BBFILE_PATTERN, BBFILE_PRIORITY, LAYERVERSION, and LAYERSERIES_COMPAT.

Q: Should I modify meta-rity directly or create a custom layer?

Always create a custom layer. Never modify meta-rity or meta-mediatek-bsp directly. Use bbappend files in your layer to extend or override recipes. Direct modifications to upstream layers create merge conflicts on every BSP update and make your changes invisible to anyone reading your layer.

Q: How do I apply a kernel DTS patch for a custom carrier board in Yocto?

Create a linux-mtk_%.bbappend in your layer's recipes-kernel directory. Add FILESEXTRAPATHS:prepend to point at your patch directory and add the patch to SRC_URI:append scoped to your machine name. This ensures the patch only applies to your board and not to EVK builds.

Q: What is the RITY skeleton pattern for custom products?

meta-rity-skeleton is a minimal template layer in the RITY repo. Copy it, rename it to meta-yourproduct, update conf/layer.conf with your collection name and layer dependencies, and add your product-specific recipes. It provides the correct structure for a RITY derivative without copying all of meta-rity.

Every Genio product that ships needs a custom Yocto layer for board-specific changes: kernel patches, device tree modifications, machine configuration, and product-specific packages. Putting these changes directly in meta-mediatek-bsp or meta-rity creates merge conflicts on every BSP update. A custom layer keeps your changes isolated and auditable.

Key Insights

conf/layer.conf is the only required file — without it, BitBake ignores the directory entirely
bbappend files are the right tool for modifying upstream recipes — never edit source recipes in other layers
Scope SRC_URI patches to your machine name — SRC_URI:append:my-machine prevents your DTS patch from applying to EVK builds
RITY skeleton (meta-rity-skeleton) is the correct starting point — copy it rather than starting from scratch
Layer priority 9 overrides base RITY (8) and BSP (7) — use it consistently across your custom layers
Use LAYERSERIES_COMPAT = "scarthgap" — build fails at layer parse time if your Yocto version isn’t listed

Step 1: Create the layer structure

mkdir meta-myproduct
cd meta-myproduct
git init

# Minimum required structure
mkdir -p conf
touch conf/layer.conf

The directory name conventionally starts with meta-. It can be anything, but meta-<product> is standard.

Step 2: Write conf/layer.conf

This is the file BitBake checks first. Every field is required:

BBPATH .= ":${LAYERDIR}"

BBFILES += "${LAYERDIR}/recipes-*/*/*.bb \
            ${LAYERDIR}/recipes-*/*/*.bbappend"

BBFILE_COLLECTIONS += "myproduct"
BBFILE_PATTERN_myproduct = "^${LAYERDIR}/"
BBFILE_PRIORITY_myproduct = "9"

LAYERVERSION_myproduct = "1"
LAYERDEPENDS_myproduct = "rity core mediatek-bsp"
LAYERSERIES_COMPAT_myproduct = "scarthgap"

Key notes:

BBPATH .= — note the .= and the leading :. This appends to the existing path. Using = instead breaks all other layers.
BBFILE_COLLECTIONS — short identifier, no hyphens. Used internally by BitBake for priority resolution.
BBFILE_PRIORITY — integer. 9 overrides RITY (8) and the MediaTek BSP (7). Use 9 for your product layer consistently.
LAYERDEPENDS — lists layers this layer requires. Build fails at parse time if a dependency is missing.
LAYERSERIES_COMPAT — space-separated. Build fails if the current Yocto version isn’t in this list.

Step 3: Add the layer to bblayers.conf

BBLAYERS += " \
  ${BSPDIR}/sources/meta-myproduct \
"

Layer order in BBLAYERS matters when priorities are equal — later entries win. Since your layer is priority 9, order is less critical, but put it after all MediaTek layers.

Step 4: Machine configuration

Create a machine config that inherits from the appropriate SoC include:

mkdir -p conf/machine

# conf/machine/my-carrier-board.conf
require conf/machine/include/mt8391.inc   # For Genio 520/720 SoC

KERNEL_DEVICETREE = "mediatek/my-carrier.dtb"
UBOOT_MACHINE = "my_carrier_defconfig"

MACHINE_FEATURES:append = " \
    alsa bluetooth pci usbgadget usbhost wifi tsn \
"

MACHINEOVERRIDES =. "my-carrier-board:"

SoC include mapping:

SoC	Include file
MT8391 (Genio 720)	`mt8391.inc`
MT8371 (Genio 520)	`mt8391.inc` (same footprint)
MT8390 (Genio 700)	`mt8188.inc`
MT8370 (Genio 510)	`mt8188.inc`
MT8395 (Genio 1200)	`mt8395.inc`

Step 5: Kernel bbappend for patches and config fragments

mkdir -p recipes-kernel/linux

# recipes-kernel/linux/linux-mtk_%.bbappend
FILESEXTRAPATHS:prepend := "${THISDIR}/${PN}:"

# Only apply to your carrier board, not to EVK builds
SRC_URI:append:my-carrier-board = " \
    file://0001-my-carrier-spi1-enable.patch \
    file://my-carrier.cfg \
"

The % wildcard in linux-mtk_%.bbappend matches any version of the kernel recipe. FILESEXTRAPATHS:prepend tells BitBake to look in your recipes-kernel/linux/linux-mtk/ directory for the patch files.

Generate the patch from your kernel source tree after making changes:

cd kernel-source
git diff arch/arm64/boot/dts/mediatek/mt8391-my-carrier.dts > \
  ../meta-myproduct/recipes-kernel/linux/linux-mtk/0001-my-carrier-spi1-enable.patch

Step 6: DTS overlays

For overlay-based DTS (DTBO), add the overlay file and extend the DTBO recipe:

mkdir -p recipes-kernel/dtbo

# recipes-kernel/dtbo/dtbo.bbappend
FILESEXTRAPATHS:prepend := "${THISDIR}/${PN}:"
SRC_URI:my-carrier-board += " \
    file://my-display.dts \
"

Use SRC_URI:machine (not SRC_URI:append) for overlays to keep them machine-scoped. The base DTBO recipe handles compilation and installation.

Step 7: Custom distro (optional)

If you need to change DISTRO_FEATURES or add product-specific configuration:

mkdir -p conf/distro

# conf/distro/my-product-distro.conf
require conf/distro/rity.inc

DISTRO = "my-product-distro"
DISTRO_NAME = "My Product"
DISTRO_VERSION = "1.0"

# Add or remove features from base RITY
DISTRO_FEATURES:append = " virtualization"
DISTRO_FEATURES:remove = "x11"

Activate in local.conf:

DISTRO = "my-product-distro"

Using the RITY skeleton pattern

meta-rity-skeleton in the RITY repo is a minimal template layer for exactly this use case. Clone it as your starting point:

# From within the RITY repo
cp -r meta-rity-skeleton ../../meta-myproduct
cd ../../meta-myproduct

# Update these in conf/layer.conf:
# - BBFILE_COLLECTIONS (change "rity-custom" to "myproduct")
# - BBFILE_PATTERN_* (match the new collection name)
# - LAYERDEPENDS (keep "rity core mediatek-bsp" at minimum)

The skeleton includes a machine config template, distro template, and example bbappend structure. It avoids the common mistake of copying too much from meta-rity itself.

Common patterns

Add product-specific packages

# recipes-myproduct/packagegroup-myproduct/packagegroup-myproduct.bb
DESCRIPTION = "My product runtime packages"
inherit packagegroup

RDEPENDS:${PN} = " \
    my-app \
    my-config \
    python3-mylib \
"

# In your image or local.conf
IMAGE_INSTALL:append = " packagegroup-myproduct"

Override a RITY recipe

# recipes-connectivity/wpa-supplicant/wpa-supplicant_%.bbappend
# Add your site-specific wpa_supplicant.conf
FILESEXTRAPATHS:prepend := "${THISDIR}/${PN}:"
SRC_URI:append:my-carrier-board = " file://wpa_supplicant.conf"

Increase rootfs size

# conf/machine/my-carrier-board.conf
IMAGE_ROOTFS_EXTRA_SPACE = "2097152"  # 2GB extra in KB

For the full RITY layer structure that your custom layer builds on top of, see What is RITY? MediaTek’s Genio reference distribution explained. For the full Yocto build workflow, see Yocto build guide for MediaTek Genio.

FAQ

What is the minimum required file for a Yocto meta layer?

A Yocto meta layer requires only conf/layer.conf. Without it, BitBake does not recognize the directory as a layer. The layer.conf must set BBPATH, BBFILES, BBFILE_COLLECTIONS, BBFILE_PATTERN, BBFILE_PRIORITY, LAYERVERSION, and LAYERSERIES_COMPAT.

Should I modify meta-rity directly or create a custom layer?

Always create a custom layer. Use bbappend files to extend or override recipes. Direct modifications to upstream layers create merge conflicts on every BSP update.

How do I apply a kernel DTS patch for a custom carrier board in Yocto?

Create a linux-mtk_%.bbappend in your layer’s recipes-kernel directory. Add FILESEXTRAPATHS:prepend to point at your patch directory and scope the patch to your machine name with SRC_URI:append:my-machine.

What is the RITY skeleton pattern for custom products?

meta-rity-skeleton is a minimal template layer in the RITY repo. Copy it, rename it, update conf/layer.conf with your collection name and layer dependencies, and add your product-specific recipes.
